- Easy ribbon loading: Hi-Lift™ metal mechanism opening to a full 90° to allow for easy ribbon access
- Heavy duty metal case for strength and durability
- Print Resolution CLS700: 203 DPi, CLS703: 300 DPi
- Ribbons up to 450 metres long either inside or outside wound with ARCP™ ribbon control
- Power switch is conveniently located at the front of the printer
- Large graphic LCD for clear indication of printer status and easy printer configuration
- Soft-close top cover for user safety and user courtesy
- Parallel, serial and USB interfaces standard; optional Ethernet and Wireless LAN
- Cross-Emulation™: Supports both Datamax® and Zebra® emulations and will sense the language being used and offer to switch emulations automatically
- Drivers: Ships with Windows™ 2000, XP, and Vista drivers
- Media capacity: Internal 203mm (8-inch) media capacity
- CLP7xxR: Rewind model
| Printing Method | Direct Thermal and Thermal Transfer |
| Printing Width | Max. 104 mm |
| Printing Length | Max. 812 mm |
| Dot Pitch | CLS700/700R: 203 dpi, 8 dots/mm CLS703/703R: 300 dpi, 8 dots/mm |
| Printing Speed (Max.) | CLS700/700R up to 254 mm (10 inches) per second CLS703/703R up to 200 mm (8 inches) per second |
| Font | 1 Scalable, 8 Bitmap, OCR-A & B True Type Font Download Standard |
| Character Table/Code Pages | See User Manual |
| Bar-code Type | 1D Codes: Code39, Code93, ITF, Codabar, UPC-A/E, EAN-8/13, UPC and EAN 2 and 5-digit extensions, Plessey, Postnet, Interleaved 2 of 5, Code128 with subsets A/B/C and UCC Case Codes, Telepen, FIM & HIBC. 2D Codes: PDF-417 & Maxi Code |
| Paper feed method | Friction Feed |
| Media Type | Roll, fanfold (Continuous media, die-cuts, continuous tags, paper or ticket) |
| Media width | Min. 25.4 mm Max. 118 mm Label Width: Min. 7.62 mm Max. 118 mm |
| Paper Roll Diameter | Max Ø 203 mm with 38 to 76 mm Core |
| Media Tickness | Min. 0.0635 mm to Max. 0.254 mm |
| Auto Cutter | Optional Cutter |
| Indicators/Controls | Graphic LCD with 4 buttons VuePrint™ Menu configuration system LED: Power, Error Buzzer:Alarms, errors etc Operating keys: Pause, Feed, Stop, Menu Power switch |
| Emulation | Datamax® (DMX400™, Prodigy Plus™, I-Class™) and Zebra® on board. Printer will sense the language being used and offer to switch emulations automatically |
| CPU | 32 Bit RISC CPU |
| Memory | SDRAM 16Mb total, 1.0 MB available for use FLASH 4MB total, 1.0MB available for use |
| Sensors | Transparent sensor, Reflective sensor & Label peeling sensor (if optional Peeler is used) |
| Interfaces | Standard with USB 1.1 (Full speed) RS-232 (Baudrate from 2400-115200) interface Parallel (IEEE 1284) Optional: Ethernet LAN or Wireless Lan. |
| Driver available | Drivers by Seagull |
| Software Utilities | Bartender Ultralite |
| Power Supply | AC100 - 240V, 1.5 - 3.5A, 50/60Hz |
| Power Consumption | Max. 3.5A |
| External Dimensions (WxDxH) | CLS700/703: 255 × 490 × 265mm CLS700R/703R: 255 × 490 × 385mm |
| Weight | CLS700/703: 13.3Kg CLS700R/703R:17.6Kg |
| Operating Environment | Temperature: 0 to 40 °C Humidity: 30 to 80% (non-condensing) |
| Storage Environment | Temperature: -20 to 60 °C Humidity: 5 to 85% (non-condensing) |
| EMC/Safety Standards | UL, C-UL, FCC: CLASS A, CE, C-Tick/RCM, CCC |
cls700_brochure.pdf
