New Zealand Stock & Warranty
All our products are New Zealand stock and come with a full manufacturer's warranty
- High Speed Dot Matrix Printing
- Build in power supply
- Fast print speed 5.1LPS
- Built in buzzer alarm
- Standard Interface: USB, RS232 & Ethernet
- Special Order: USB & Parallel version
- ESC/POS compatible
- Easy to use:
- - Drop in Paper loading
- - Eliminates Paper Jams
- Easy update logos and firmware using Storemaker
- SRP275IIIA - Tear Bar Version
- Available in Dark Grey
| Printing Method | 9 Pin Serial Dot Matrix Bi-directional Printing |
| Printing Width | Up to 63.5 mm |
| Dot Pitch | 80 dpi horizontal 144 dpi vertical |
| Printing Speed (Max.) | 40 Column Printer Approx. 5.1 lines/sec |
| Number of Columns | Font A: 35 Column Font B: 40 Column KOR: 20 Column CHN: 22 Column |
| Character Size | Font A: 9 x 9 Font B: 7 x 9 KOR: 17 x 9 CHN: 16 x 16 |
| Character Table/Code Pages | Alphanumeric: 95 Extended Graphics 128 x 27 Page International: 48 |
| Bar-code Type | N/A |
| Line Spacing | N/A |
| Paper feed method | Friction |
| Paper Type | Plain Bond Paper or 2 ply Paper |
| Paper Width | 76 mm +/-0.5 mm |
| Paper Roll Diameter | Max Ø 83.0mm |
| Paper Thickness | 0.06 ~ 0.085 mm |
| Paper Supply Method | Easy Drop in Paper loading |
| Indicators/Controls | Power LED Green Paper LED Red Error LED Red |
| Emulation | BXL/POS |
| Print Buffer | 64K bytes |
| NV Memory | 256 KBytes (Mono) |
| Sensors | Paper end, Paper near end Sensor |
| Drawer Port | 1 port (opens 2 drawers, special cable is needed to open 2 drawers) |
| External Device Port | N/A |
| Interfaces | Standard: Serial (RS-232C compliant), USB V2.0 & Ethernet (DHCP Enabled), or (Special Order) USB V2.0 & Parallel (IEEE1284 compliant) |
| Driver available | Windows Driver, OPOS Driver, JPOS Driver, Linux, Mac CUPS Driver Virtual COM USB/Ethernet Driver |
| Software Utilities | Utility Program |
| Power Supply | Internal AC Adapter Rated input: 100-240 AV, 50/60 Hz |
| Power Consumption | Energy Star Certified |
| External Dimensions (WxDxH) | 160 × 239 × 157 mm |
| Weight | SRP275IIIC: 2.5 Kg SRP275IIIA: 2.4 Kg |
| Operating Environment | 0 to 40 °C, 10 to 80 % RH (no condensation) |
| Storage Environment | 10 to 90 °C, 10 to 90 % RH (no condensation) |
| Reliability | 18 million Characters |
| EMC/Safety Standards | TÜV-GS, CE marking, C-tick |
| Warranty | 1 Year Back to Base |
srp275III_brochure.pdf
